Display
5-inch Touch Screen
Face Capacity
6,000
Palm Capacity
3,000
Card Capacity
10,000
Transaction Capacity
200,000
Standard Functions
ID Card, ADMS, T9 Input, DST, Camera, 9-digit User ID, Access Levels, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods
Hardware
900MHz Dual Core CPU, Memory 1G RAM / 8G Flash, 2MP WDR Low Light Camera, Adjustable Light Brightness LED, Barcodes Scanning
Communication
TCP/IP, Wi-Fi (Optional), Wiegand Input / Output, RS485
QR Sensor
QR Code, PDF417, Data Matrix, MicroPDF417, Aztec
Access Control Interface
3rd-Party Electric Lock, Door Sensor, Exit Button, Auxiliary Input, Auxiliary Output (Alarm)
Optional Functions
13.56MHz IC Card
Biometrics Algorithm
ZKFace V5.8 & ZKPalm V12.0
Power Supply
DC 12V 3A
Operating Humidity
10% to 90%
Operating Temperature
-10°C to 45°C (14°F to 113°F)
Dimension
91.93 * 202.93 * 21.5 (mm) (W*H*D)
Supported Software
ZKBioSecurity / ZKBioSecurity Mobile App
