RS485 is currently a widely used communication interface in data acquisition and control applications where multiple nodes communicate with each other. RS485 is also the most versatile communcation standard in the standard series defined by the EIA. In circumstances which require to use multiple readers, RS485 communication shows how it is important. With RS485 readers, you can reduce the cost of control panel and make the control much more accurate. RS485 Reader Series let you connect multiple readers to the control panel in one single RS485 port, which can enlarge the control panel card reader capacity. Also, RS485 has excellent transfer rate that allows long-distance transfer up to 1200m (theoretical value). Therefore, RS485 reader are perfect tool for multiple access solutions in scalable area.
Read Range
KRxxx-E: Up to 10CM
KRxxx-M: Up to 5CM
Reading Time
≤ 200ms
Input Port
External LED Control
External Buzzer Control
Supported Panel
InBio160, InBio260, InBio460
Power Supply
DC 6-14V / Max.70mA
Operating Humidity
10% to 90% relative humidity non-condensing
Material
ABS + PC with texture
Beeper
Yes
LED
Red and Green LEDs
Ingress Protection Rating
KR100M-RS: IP65
Output Format
RS485
Operating Temperature
-20°C to 65°C (-10° to +70°C)
