Model
LB12 / LB22 / LB35
Power Supply
DC 10V to 24V
Wiring
LB12: 2 wire Regardless + or –
LB22: 2 wire Red: + Black: –
LB35: 5 wire Red: + Black: – Yellow: Exit button (work with Black) White: Door sensor, COM Blue: Door sensor, NO
Lock Delay
LB12: N / A
LB22: 0s,3s,or 6s (adjustable)
LB35: 0s,3s,or 6s (adjustable)
Unlock Delay
LB12: N / A
LB22: 6s (automatically locks the door again when no one pushes the door within 6s after unlocking)LB35 : 0s,3s,or 6s(adjustable)
LB35: 6s (automatically locks the door again when no one pushes the door within 6s after unlocking)
Door Sensor
LB12: N / A
LB22: N / A
LB35: Supports
Lock Cylinder
SUS304 Stainless Steel
Installation Hole Size
207 * 36 (mm) (The depth of the inner pit is not less than 38mm) (L*W)
Decorative Panel Size
215 * 41 * 0.7 (mm) (L*W*H)
Lock Panel Size
205 * 35 * 3 (mm) (L*W*H)
Gross Weight
LB12: 0.445kg
LB22: 0.719kg
LB35: 0.719kg
