Display
7-inch Touch Screen
Face Capacity
10,000
Fingerprint Capacity
10,000 (Optional)
Card Capacity
10,000 (Optional)
Transaction Capacity
200,000
Standard Functions
ADMS, T9 Input, DST, Camera, 9-digit User ID, Acess Levels, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verify Modes
Hardware
900MHz Dual Core CPU Memory 512MB RAM / 8G Flash 2MP WDR Low Light Camera Adjustable Light Brightness LED
Communication
TCP/IP, WiFi (Optional), Wiegand input / output, RS485
Access Control Interface
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm output, Auxiliary Input
Optional Functions
125KHz ID card (EM) / 13.56MHz IC card, Fingerprint
Biometrics Algorithm
ZKFace V5.8 & ZKFinger V10.0
Power Supply
12V 3A
Operating Humidity
20% – 80%
Operating Temperature
0 °C – 45 °C
Dimension
91.93 * 202.93 * 21.5mm (W*H*D)
Supported Software
ZKBio Access IVS
