Details
TS-832PX-4G
High-capacity NAS devices with 10GbE SFP + and 2.5GbE ports support PCIe expansion for M.2 SSD to speed up applications
Link to the manufacturer website: https://www.qnap.com/en-us/product/ts-832px
Compatibility list for this model: https://www.qnap.com/en-en/compatibility/?model=478&category=1
Link to CZ video: https://www.mall.tv/ze-zivota-fotografa/vyzkouseno-overeno-nejlepsi-tipy-jak-zalohovat-fotky-a-na-co-si-dat-pozor
Function
Equipped with eight 3.5 “SATA 6GB/s slots, the TS-832PX quad-core 1.7GHz processor offers huge storage potential for a wide range of applications and everyday use. With two 10GbE SFP + ports and two 2.5GbE LAN ports, the TS-832PX supports 832PX next-generation networking to streamline bandwidth-intensive applications for smoother file access and sharing, as well as a variety of PCIe cards, including QM2 cards that provide M.2 SATA/NVMe SSD cache and automatic Qtier automatické scaling for increased performance OUR.
PACKAGE CONTENTS
TS-832PX
Ethernet cable x 1
Power Cord x 1
Flat head screw (for 3.5 “HDD) x 32
Flat head screw (for 2.5 “HDD) x 24
Quick Installation Guide (QIG)
Drive tray keys x 2
SPECIFICATIONS
Processor
AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 Quad-Core 1.7 GHz Processor
CPU architecture
64-bit ARM
Floating point unit
Yes
Encryption module
Yes
System memory
4 GB SODIMM DDR4 (1 x 4 GB)
Maximum memory
16 GB (1 x 16 GB)
Memory slot
1 x SO-DIMM DDR4
Flash memory
512 MB (dual OS protection at startup)
Disk drive bays
8 x 3.5 “SATA 6 Gb/s, 3 Gb/s
Disk drive compatibility
3.5 “position:
3.5 “SATA hard disk drives
2.5 “SATA hard disk drives
2.5 “SATA SSD
Hot-swap
Yes
Slot for M.2 SSD
Optional via PCIe adapter
SSD cache acceleration support
Yes
2.5 Gigabit Ethernet port (2.5G/1G/100M)
2 (also supports 10M)
10 gigabit Ethernet port
2 x 10GbE SFP +
Wake on LAN (WOL)
Yes
2.5GbE port only
Jumbo frame
Yes
PCIe slot
1
Slot 1: PCIe Gen 2 x2
PCIe bandwidth throttling will reduce the performance of a 10GbE NAS.
USB 3.2 Gen 1 port
3
Shape factor
Table
LED indicators
System status, LAN, USB, HDD1 ~ 8
Buttons
Power, reset, copy to USB
Dimensions (H x W x D)
188.2 × 329.3 × 280.8 mm
Weight (net)
6.38 kg
Weight (total)
8.61 kg
Operating temperature
0 – 40 ° C (32 ° F – 104 ° F)
Relative humidity
Relative humidity 5 to -95%, no condensation, wet bulb temperature: 27 ° C (80.6 ° F)
Power supply unit
250 W, 100–240 V AC, 50/60Hz, 3.5 A
Power consumption: HDD sleep mode
27,949 W
Power consumption: Operating mode, typical
50,858 W
Ventilator
System fan: 2 x 120 mm, 12V DC
CPU fan: 1 x 60 mm
Sound level
19.6 db (A)
System warning
Voice instructions or buzzer
Kensington security slot
Yes
Max. number of concurrent connections (CIFS)
1500
Technical Specification
Case Type Desktop
Drive Bays 8x
No. of 3.5″ HDD 8
No. of 2.5” HDD 8
Max Capacity (TB) 128
HDMI No
Connection Type 10GbE
No. of LAN Ports 2
No. of USB Ports 3
No. of SFP + Ports 2
CPU Series Other
CPU Model AnnapurnaLabs Alpine AL324 ARM Cortex-A57
No. of Cores 4
CPU Clock Speed (range) 1.6 – 2.0 GHz
CPU Clock Speed (exact) 1.7 GHz
Memory Type DDR4
Memory Size (GB) 4
Package
Nr. of pcs in package 1
Weight (kg) 9.9046
Dimensions (cm) 42.5×29.5×39.5
Length (cm) 39.5
