Details
TS-431XeU
Short depth rackmount NAS with quad-core processor and 10GbE SFP + port
Link to manufacturer website: https://www.qnap.com/en-us/product/ts-431xeu
Compatibility list for this model: https://www.qnap.com/en-us/compatibility/?model=291
Function
The powerful quad-core TS-431XeU short depth includes a 10GbE SFP + port for full support for 10GbE high-speed networks at a low cost with maximum return on investment. The short depth design is perfect for installing the TS-431XeU in a compact stand or in places with a large number of cables. The TS-431XeU offers versatile and comprehensive features and includes the unique Virtual JBOD (VJBOD) – an economical way to use unused NAS space to expand the storage capacity of other QNAP NASs and Container Station to enable users to quickly develop and deploy IoT applications ). The TS-431XeU is a cost-effective storage solution designed for growing businesses requiring backup, recovery, private cloud, storage for virtualization, and providing the company IT infrastructure for future 10GbE network entry.
The short depth design is suitable for installation in smaller rack cabinets or open rooms
Supports 10GbE, SSD caching and encryption acceleration module
VJBOD allows you to use the TS-431XeU to extend the storage capacity of another QNAP NAS
Enjoy containerized virtualization and application development for IoT with Container Station
Create a private cloud to centrally organize and manage your files and backup tasks
Secure access with VPN Server and VPN Client
Qsirch, a full-text search engine, helps you quickly find files on your NAS
Expand total capacity up to 24 units by connecting up to two QNAP expansion units (UX-1200U-RP or UX-800U-RP)
PACKAGE CONTENTS
TS-431XeU
Ethernet cable
Power Cord
Quick Installation Guide (QIG);
Power cord
Flat head screw (for 2.5 “HDD)
Infrared (IR) Remote Control: RM-IR003
SPECIFICATIONS
Ordering P/N:
TS-431Xe-2G
CPU:
Processor: AnnapurnaLabs, a Amazon company, Alpine AL-314 Quad-Core 1.7GHz
System Memory
1 x 2GB SO DIMM DDR3-1600
Maximum Memory
1 x 8GB SO DIMM DDR3
Memory Slots:
1
Flash memory
512MB (double OS protection at startup)
Hard Drive Tray
4
Drive Interface:
SATA 6 Gbps, HDD or SSD
Drive Type
3.5-inch or 2.5-inch
10GbE LAN
1 x 10 Gigabit SFP + port
GbE LAN
2 x Gigabit RJ45 LAN port
USB
4 x USB 3.0
Storage expansion:
1x UX-800U-RP and 1x UX-1200U-RP
2 x UX-800U-RP
1x UX-800U-RP or UX-1200U-RP
Up to 24 drives are supported.
Fan:
3 x 4cm fan system (12V DC)
Power Supply:
100W, 100 – 240V AC, 50/60Hz, open frame
LED Indicators
HDD1, HDD2, HDD4, LAN1, LAN2, 10GbE, STATUS
Buttons
Power, Reset
Other I/O
Kensington Security Slot, Console Port
System Warning
Buzzer
Form Factor:
1U
Dimension (H x W x D)
44 x 439 x 291mm
Weight
4.15 kg (net); 5.78 kg (lb)
Operating Temperature:
0 to 40 degrees Celsius
Relative Humidity
5 to 95% non-condensing, wet bulb: 27 degree of Celsius
Noise Level; Sound level (dB):
20.3
Power Consumption
HDD Standby: 12.42
In operation: 30.99
(With 4 x2TB HDDs installed)
Technical Specification
Case Type Tower
Drive Bays 4x
Hard Drive Positions up to 4
Max Capacity (TB) 64
No. of LAN Ports 2
No. of USB Ports 4
No. of SFP + Ports 1
CPU Series ARM
CPU Model Alpine AL-314
No. of Cores 4
CPU Clock Speed (range) 1.6 – 2.0 GHz
CPU Clock Speed (exact) 1.7 GHz
Memory Type DDR3
Memory Size (GB) 2
Package
Nr. of pcs in package 1
Weight (kg) 5.6420
Dimensions (cm) 31x26x35
Length (cm) 35
