GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference.
PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion.
AUTO-SENSING PORTS
Automatically optimize speed for each connected device.
TECHNICAL SPECS
Model Name:
LGS116
Network Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3az
Ports:
16 Gigabit Ethernet (10/100/1000) Ports
LEDs:
Link, speed, and activity indicators
Performance:
Full line rate and forwarding rate of 64B frame at:
1.488Mpps for 1000M port
0.1488Mpps for 100M port
0.01488Mpps for 10M port
MAC Address Table Size:
8K
Bandwidth:
32 Gbps (non-blocking)
Fans:
None
Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables
Dimensions (LxWxH):
288 x 102 x 26 mm
Weight:
0.703 kg
Power:
12 VDC, 1 A
Power Consumption:
2.36W/8.01W
Power Consumption:
2.66 W / 9.32 W
Power Saving:
Cable connected detection, sleep mode
Power Supply:
External
Operating Temperature:
0–50°C
Storage Temperature:
-40–70°C
Operating Humidity:
10–90% (non-condensing)
Storage Humidity:
10–90% (non-condensing)
Quality Of Service:
802.1p and DSCP
Regulatory Compliance:
FCC Class B, CE
Warranty and Support:
5 Year Warranty
