Native resolution
4K UHD 3840 x 2160 (16:9)
Backlight
Direct-lit LED
LED lifespan
50,000 hours to 50% brightness
Display orientation
Portrait and landscape
Pixel pitch (WxH)
0.57 x 0.57mm
Bezel width
16mm
Brightness (typical) – (cd/sq m)
500 nits
Contrast ratio (typical)
1,200:1
Viewing angle (CR 10:1)
178 degrees h/v
Refresh rate
120Hz
Response time (typical)
8ms
Color space typical (CIE 1931)
72%
Display colors
10 bit, 1.07 billion
Video inputs
4 x HDMI™ (Ver 2.0b, HDCP 2.2)
DisplayPort™ (Ver 1.4)
OPS
Audio outputs
3.5mm headphone jack
Control inputs
RS-232 (D-Sub9)
LAN (RJ45)
IR wire extender
USB-A2.0 for service
Power input rating
110-240 VAC @ 50/60Hz
Power consumption
600W maximum (without OPS)
<=0.5W in standby (without OPS)
Operating temperature
32-104°F (0-40°C)
Storage temperature
-4-140°F (-20-60°C)
Operating humidity
20-90% RH non-condensing
Size (panel only)
(WxHxD) 86.4 x 49.2 x 3.8" (2195 x 1250 x 96mm)
Weight
209.4lbs (95kg)
Mounting
VESA 800mm x 400mm, M8
Runtime
Designed for 24/7 operation featuring a reliable power supply*
Features
Commercial-grade LCD with LED backlight
OPS slot
Anti-glare treatment
2 x 15W speakers
HDMI-CEC
DICOM simulation
HDR10 compatible
Priority Input Source
Source switching for failover
No RF capability
4 window multi-source UHD viewing (Quadview, PiP, PBP)
MEMC
Crestron Connected 2
Accessories
Panel ships with IR remote control
HDMI 2.0 3M cable
External IR receiver
Power cable
Product safety guide
Warranty
Three years parts and labor limited warranty
Contact an authorized Christie representative for full details of our limited warranty
