Native resolution
4K UHD 3840 x 2160 (16:9)
Backlight
Edge-lit LED
LED lifespan
30,000 hours to 50% brightness
Display orientation
Landscape
Pixel pitch (WxH)
0.429 x 0.429mm
Bezel size (bottom/side/top)
19mm/19mm/19mm
Brightness (typical) – (cd/sq m)
450 nits
Contrast ratio (typical)
1,200:1
Viewing angle (CR 10:1)
178 degrees h/v
Refresh rate
60Hz
Response time (typical)
8ms
Color space typical (CIE 1931)
68%
Display colors
10 bit, 1.07 billion
Video inputs
4 x HDMI (Ver 2.0b, HDCP 2.2)
DisplayPort Ver 1.2
OPS
Audio outputs
3.5mm headphone jack
Control inputs
RS-232 via D-Sub9
LAN via RJ45
IR wire extender
USB-A2.0 for service
Power input rating
100-240 VAC @ 50/60Hz
Power consumption
230W maximum without OPS
0.5W standby without OPS
Operating temperature
32-104°F (0-40°C)
Storage temperature
-4-140°F (-20-60°C)
Operating humidity
20-90% RH non-condensing
Physical size (panel only)
(WxHxD): 66.7 x 38.3 x 2.7″ (1693 x 972 x 69mm)
Weight
84lbs (38.2kg)
Mounting
VESA (WxH) 600 x 400mm
M8
Runtime
Recommended for 18/7 operation featuring a reliable power supply*
Features
Commercial-grade LCD with LED backlight
OPS slot
Anti-glare treatment
2 x 15W speakers
HDMI-CEC
DICOM simulation
HDR10 compatible
Priority Input Source
Source switching for failover
No RF capability
4 window multi-source UHD viewing (Quadview, PiP, PBP)
MEMC
Crestron Connected 2
Accessories
Panel ships with HDMI 2.0 Cable, RS232 Cable, Remote Control with batteries, IR receiver
Warranty
Three years parts and labor limited warranty
Contact an authorized Christie® representative for full details of our limited warranty
